ELGi EQ 25 HP rotary screw air compressor, Base mount

Shown: ELGi EQ 37 base mount. Size varies by model.

Flow: 100 CFM
Pressure: 125 PSI
Sound: 70 dB(A)
Airend: 6-yr warranty

ELGi · Part EQ18-125 base mount

ELGi EQ Series Direct-Drive Rotary Screw Air Compressor

100 CFM @ 125 PSI · Fixed speed · Base mount · 460V 3-phase

Horsepower

Drive

Package

Working pressure (PSI)

Electrical

Other voltages quoted by phone.

$15,770.16

Freight quoted by phoneFactory start-up available

Call to order · 866-203-9939

Mention part EQ18-125 base mount. A live expert confirms sizing and ship date.

Pay your way

Credit card, ACH or PO

Financing — apply online

24–60 months, decisions in about 2 hours

Technical specifications

Showing EQ18-125 base mount

Performance

Model	EQ18
Motor power	25 HP / 18 kW
Free air delivery	100 CFM @ 125 PSI
Working pressure	125 psig
Sound level	70 dB(A)
Drive	Direct drive, oil-lubricated

Electrical & controls

Voltage	460V 3-phase · 60 Hz
Main motor	TEFC, severe industrial duty
Capacity control	Load / unload
Controller	Neuron XT — protection, remote monitoring, fault reports
Starting	Reduced starting current, integrated intake & blowdown valve
Cooling	Air-cooled, rated to 122°F ambient

Package & dimensions

Configuration	Base mount
Air treatment	Aftercooler; dryer optional
L × W × H	59 × 32.3 × 48 in
Weight	1,477 lbs
Filtration	Multi-stage intake filtration, 4,000 hr consumables
Service	Minimum 4,000 hour service interval

Flow at each pressure — 25 HP fixed speed

100 PSI

111 CFM

125 PSI

100 CFM

150 PSI

87 CFM

175 PSI

78 CFM

Free air delivery per ISO 1217:2009 (Annex C fixed speed, Annex E VFD); sound per ISO 2151. From the ELGi EQ series brochure. Dimensions and weight are for base mount.

Compare EQ sizes

Fixed speed flow at 100, 125 and 150 PSI. Select a row to configure that size.

HP	Model	CFM @100	CFM @125	CFM @150	Weight (lbs)	L × W × H (in)	From
25 HP	EQ18	111	100	87	1,477	59 × 32.3 × 48	$15,770.16
30 HP	EQ22	134	118	109	1,488	59 × 32.3 × 48	$16,542.00
40 HP	EQ30	191	182	144	2,260	67 × 44 × 55.5	$22,630.32
50 HP	EQ37	237	209	188	2,469	67 × 44 × 55.5	$24,472.08
60 HP	EQ45	284	262	227	2,491	67 × 44 × 55.5	$29,200.32

Direct drive for tough plants

The ELGi EQ is an oil-lubricated, direct-drive rotary screw from 25 to 60 HP, built for dusty, humid and hot plants — rated for 122°F ambient, with heavy-duty multi-stage intake filtration that stretches consumables to 4,000 hours.

Choose fixed speed or VFD on every size. The 25 and 30 HP models are also offered on a 120 gallon tank, with or without an EGRD refrigerated dryer. ELGi covers the EQ with a 6-year airend and 5-year package warranty, no service contract required.

Standard features

Direct drive, no belts
Optional integrated VFD
Neuron XT controller
Rated to 122°F ambient
Multi-stage intake filtration
TEFC severe-duty motor
Reduced starting current
4,000 hr service interval

Warranty

ELGi's EQ warranty requires no service contract. Terms and conditions apply — a guru will send the full warranty with your quote.

Coverage	Term
Airend	6 years, no running-hour limit
Complete package	5 years
VFD	3 years
Rubber, electrical & plastic parts	1 year

Per ELGi EQ series literature. Use genuine ELGi parts and Airlube fluid.
