- Pumping speed
- 1.5 CFM
- Ultimate
- 3.7 x 10⁻³ Torr
- Type
- Oil-sealed
NAVAC ShieldDrive Series Two-Stage Vacuum Pumps
NAVAC ShieldDrive Series Oil-Sealed Rotary Vane Vacuum Pump — SD2
Mention part SD2. A live expert confirms sizing and ship date.
Technical specifications
Showing SD2Specifications from NAVAC. Part numbers confirmed when you order.
Compare models
Base price shown for each model. Select a row to configure it.
| Model | Pumping speed | Motor / vacuum | Electrical | From | From | |
|---|---|---|---|---|---|---|
| SD2 | 1.5 CFM | 3.7 x 10⁻³ Torr | 115V/1PH/60Hz | $3,619.00 | ||
| SD8 | 4.7 CFM | 3.7 x 10⁻³ Torr | 115V/1PH/60Hz | $4,441.00 | ||
| SD12 | 5.9 CFM | 3.7 x 10⁻³ Torr | 115V/1PH/60Hz | $5,302.00 |
NAVAC ShieldDrive Series Two-Stage Vacuum Pumps
The NAVAC ShieldDrive Series is a two-stage oil-sealed rotary vane pump built for leak-free operation. Instead of a dynamic shaft seal it uses a static seal with a mechanical shield and magnetic coupling, so oil cannot migrate out of the pump.
A brushless DC motor with Eco Mode keeps it efficient and quiet, which makes it a strong fit for laboratories and other critical, clean applications.
Standard features
- Two-stage oil-sealed rotary vane
- Static seal with mechanical shield and magnetic coupling
- No oil migration or shaft-seal leaks
- 1.5 to 5.9 CFM pumping speed
- Ultimate pressure 3.7 x 10⁻³ Torr (2.2 x 10⁻² Torr with gas ballast)
- Brushless DC motor with Eco Mode
- Anti-suck back design
- Adjustable gas ballast
- Mineral oil included
- 115V 1-phase 60 Hz
Warranty
NAVAC factory warranty and support are available. A guru will send current warranty terms with your quote.
| Coverage | Term |
|---|---|
| Factory warranty | NAVAC standard |
| Service | Local service available on all brands |
Use genuine NAVAC parts and follow the maintenance schedule to keep coverage.
