Quincy QGD 25 HP rotary screw air compressor

Flow: 109.8 ACFM
Pressure: 125 PSI
Sound: 68 dB(A)
Airend: 5-yr ext.

Quincy Compressor · Part QGD-25-BM

Quincy QGD & QGDV Direct-Drive Rotary Screw Air Compressor

109.8 ACFM @ 125 PSI · Fixed speed · Base mount · 460V 3-phase

Horsepower

Drive

Package

Rated pressure (PSI)

Electrical

Same price across voltages — confirm voltage when you order.

$27,372.55

Freight quoted by phoneCall for Availability

Call to order · 866-203-9939

Mention part QGD-25-BM. A live expert confirms sizing and ship date.

Pay your way

Credit card, ACH or PO

Financing — apply online

24–60 months, decisions in about 2 hours

Technical specifications

Showing QGD-25-BM

Performance

Model	QGD-25
Motor power	25 HP / 18 kW
Capacity	109.8 ACFM @ 125 PSI
Rated pressure	125 psig
Sound level	68 dB(A)
Drive	Direct drive, fixed speed

Electrical & controls

Voltage	460V 3-phase · 60 Hz
Main motor	NEMA premium efficiency TEFC
Starter	Wye-delta
Controller	Airlogic2 — dual set point, scheduling, networks up to 6 units
Electrical enclosure	NEMA 4
Protection	Phase monitor, auto-restart after power loss

Package & dimensions

Configuration	Base mount
Air treatment	Aftercooler; dryer optional
L × W × H	56.4 × 33.1 × 50.3 in
Weight	1,122 lbs
Service access	Boltless hinged doors, single-panel consumables
Intake	Package air pre-filtration

Flow at each pressure — 25 HP QGD

100 PSI

124 CFM

125 PSI

109.8 CFM

150 PSI

102.3 CFM

Performance per ISO 1217 Ed. 4, from the Quincy QGD / QGDV datasheet. Dimensions and weight are for the base-mount package.

Compare QGD sizes

Flow at 125 PSI. Dimensions and weight for base mount. Select a row to configure that size.

HP	QGD CFM	QGDV CFM	dB(A)	L × W × H (in)	Weight (lbs)	From
15 HP	70.1	72.3	66	56.4 × 33.1 × 50.3	1,071	$21,364.75
20 HP	97.2	96.2	67	56.4 × 33.1 × 50.3	1,089	$24,877.80
25 HP	109.8	117.6	68	56.4 × 33.1 × 50.3	1,122	$27,372.55
30 HP	132.2	141.3	69	56.4 × 33.1 × 50.3	1,157	$30,069.60
40 HP	192.6	—	66	51.2 × 35 × 70.5	1,415	$30,734.30
50 HP	229.7	—	67	51.2 × 35 × 70.5	1,536	$31,589.40
60 HP	273.3	—	68	51.2 × 35 × 70.5	1,639	$36,390.20

Direct drive, quiet, made for production

The Quincy QGD is a direct-drive rotary screw from 15 to 60 HP — no belts to tension or replace — running as quietly as 66 dB(A). The QGDV adds a variable speed drive in 15 to 30 HP to follow your demand and cut energy use.

The Airlogic2 controller schedules the compressor, holds dual set points and networks up to six units. Base mount, base mount with dryer, and 120 gallon tank-mount packages are available, and Quincy's extended warranty covers the airend, cooler, receiver and motor for 5 years with an authorized start-up.

Standard features

Direct drive, no belts
High-efficiency airend
Airlogic2 controller
NEMA 4 electrical enclosure
Wye-delta start (fixed speed)
Boltless hinged doors
Spin-on filters (15–30 HP)
Phase monitor & auto-restart

Warranty

Coverage starts at the earlier of 12 months from start-up or 18 months from factory shipment. The 5-year extended plan requires an authorized start-up.

Coverage	Term
Standard	1 year on the basic compressor
Extended — airend	5 years
Extended — cooler & receiver	5 years
Extended — drive motor	5 years

Use genuine Quincy parts and QuinSyn fluid to keep extended coverage.
